Residual Heat Recovery System for Hot Dip Galvanizing Production Line

Complete Zinc Kettle Supplier Services

We supply reliable, high-performance, environmentally friendly, technological, and modern galvanizing factories with comprehensive one-stop service solutions.

Design Guidance

Superconducting heat pipes serve as the main heat-conducting components of waste heat recovery devices
Heat exchange efficiency of heating pipe-type waste heat recycling systems can exceed 98%, significantly outperforming ordinary heat exchangers

Working Principle of Heating Pipes

The lower section functions as the flue, the upper section contains water pipes, separated by a partition board
During operation, flue gas flows through the waste heat recycling system flue, washing the lower end of heating pipes
Heating pipes absorb heat and transfer it to the upper end, where heat is released to warm the water

Construction Details: Heat pipes are manufactured from steel, copper, and aluminum tubes filled with heat-conducting media, drawn to specific vacuum levels, and sealed. The heat-conducting medium consists of inorganic active metals and their compounds, exhibiting exceptional thermal activity and sensitivity.

Thermal Properties: The superconducting fluid activates at specific temperatures, transferring heat through molecular oscillation phase transition. Thermal conductivity is approximately 10,000 times greater than ordinary metals, with no heat transfer temperature decay and exceptionally rapid transfer speeds.

Our Comprehensive Services

Zinc Kettle Design: Optimal dimension selection based on plant size, material specifications, and processing capacity
Plant Layout: Strategic arrangement considering land size, environmental requirements, and galvanizing processes
Civil Work Design: Comprehensive calculations and building drawings for steel and concrete structures
HDG Equipment Manufacturing: Complete galvanizing factory equipment production from essential to auxiliary systems
Installation & Commissioning: Professional installation services, user guidance, chemical supply, and technical adjustments

Main Equipment Overview

No.	HDG Process	Equipment	Purpose
1	Pickling	Enclosed pretreatment workshop Acid fume treatment equipment Pickling electric hoist/crane	Collect acid fume Environmental protection Material transfer
2	Rinsing	Wastewater treatment equipment	Environmental protection
3	Degreasing	Waste heat recycling system	Energy conservation
4	Rinsing	Wastewater treatment equipment	Environmental protection
5	Fluxing	Waste heat recycling system Iron removal equipment	Energy conservation Recycling efficiency
6	Galvanizing	Galvanizing furnace body Zinc kettle White fume fixed hood White fume treatment equipment Bridge crane/electric hoist	Heating application Zinc placement Fume collection Environmental protection Material transfer
7	Cooling	Cooling tower	Water recycling
8	Passivation	Chromium-free passivator	Effective coating
9	Auxiliary	Bridge crane/Flat trolley/Material rack/Transfer pit Tank's anti-corrosion protection Zinc ingot/Chemicals/Alloy	Material handling Safety assurance Essential supplies

Service Process

Demand communication and analysis
Custom plant design and planning
Supply of hot dip galvanizing equipment
Professional assembly and commissioning
Supply of advanced galvanizing techniques
24-hour after-sales service support

Galvanizing Training Programs

Comprehensive theory of hot dip galvanizing
Zinc ingot melting procedures and best practices
Zinc kettle operation and maintenance guidance
Fume reduction and control techniques
Coating problem diagnosis and treatment
Chemical additive adjustment and optimization

Production Line Selection Guidance

Several critical factors influence the selection of appropriate production lines and kettle sizes:

Available land size and facility constraints
Material types, sizes, and production quantities
Environmental protection requirements and regulations

Important Considerations: Hot dip galvanizing is not suitable for all product coatings. Some products may require alternative plating methods, necessitating different production line configurations.

Operational Commitment: Once operational, galvanizing facilities cannot be stopped arbitrarily. Zinc solutions must remain molten year-round, requiring continuous operation and substantial workload to offset costs and generate profits.

Kettle Sizing Strategy: Optimal kettle size is determined by the largest parts in highest production volume. For example, if 12m pipes represent a small portion of production while 6m steel structures dominate, we recommend against 12.5m kettles. Provide your part specifications for customized kettle design recommendations.

Why Choose Us

Beihai Galvanizing - Your tailored factory solution, worthy of your trust and investment.

Partner with us for a mutually beneficial future and sustainable business growth.
