Environmental Friendly Hot Dip Galvanizing Furnace Equipment Production Line Galvanizing White Fume Treatment Supplier
Environmental Friendly Hot Dip Galvanizing Furnace Equipment Production Line Galvanizing White Fume Treatment Supplier
Environmental Friendly Hot Dip Galvanizing Furnace Equipment Production Line Galvanizing White Fume Treatment Supplier Environmental Friendly Hot Dip Galvanizing Furnace Equipment Production Line Galvanizing White Fume Treatment Supplier Environmental Friendly Hot Dip Galvanizing Furnace Equipment Production Line Galvanizing White Fume Treatment Supplier Environmental Friendly Hot Dip Galvanizing Furnace Equipment Production Line Galvanizing White Fume Treatment Supplier Environmental Friendly Hot Dip Galvanizing Furnace Equipment Production Line Galvanizing White Fume Treatment Supplier Environmental Friendly Hot Dip Galvanizing Furnace Equipment Production Line Galvanizing White Fume Treatment Supplier

Environmental Friendly Hot Dip Galvanizing Furnace Equipment Production Line Galvanizing White Fume Treatment Supplier

Product Details:
Place of Origin: China
Brand Name: Beihai Galvanizing
Model Number: Non-standard
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Like wooden box, suit for shipping and lifting
Delivery Time: 60-120 working days
Payment Terms: L/C, T/T
Supply Ability: No limit
Contact Now
  • Detail Information
  • Product Description

Detail Information
Company Type: Manufacturing And Trading Origin: CHINA/TAIWAN Since 1990
Scope: Equipment For A Complete Hot Dip Galvanizing Plant Advantage: High Quality
Application: For Galvanizing Various Steel Parts After-sales Service Provided: Engineers Available To Service Machinery Overseas,Field Maintenance And Repair Service
Condition: New Type: Hot Dip Galvanizing
Coating: Galvanizing, Zinc Or Zn-Al, Hot Dip Galvanizing Dimension(l*w*h): Customized
Product Name: Hot Dip Galvanizing Line Color: Customized Color
Control: Smart Control Furnace: High Velocity Pulse Firing System
Customers: Worldwide Burner: High Velocity Pulse Fired Burner
Size: Make As Customer Need Or We Design
Highlight:

Environmental Friendly Galvanizing Furnace Equipment

,

White Fume Treatment Galvanizing Furnace Equipment

,

Hot Dip Galvanizing Furnace Equipment

Product Description

Environmental Friendly Hot Dip Galvanizing Furnace Equipment Production Line Galvanizing White Fume Treatment Supplier



The main source of the waste gas/fume

The white fume is produced from the hot dip galvanizing process. Generally, the molten zinc surface can quickly form an oxide layer, and the amount of fume is less. But once the workpiece dips in and takes out of the zinc kettle, the fume increases suddenly because of the stirring and volatilization of the fluxing agent.

White fume collection
The white fume collecting part is designed with a top suction hood above the zinc kettle. The fume is sucked into the treatment equipment, and the capture rate can reach more than 98%.

Waste gas/fume Treatment Process Flow
White fume suction→ Dust collector→ Filter → Pulse air back blowing→ Ash hopper vibrating and cleaning→ Emission



We supply reliable, high-performance, environmentally friendly, technological, and modern galvanizing factories.

Our service:

  • Design zinc kettle: choosing the best dimension for the galvanizing kettle according to the plant size, material size and dealing capacity.
  • Plant layout: arranging the plant according to the land size, environmental requirement, and galvanizing process
  • Civil work design: supplying calculations and building drawings in steel and concrete.
  • HDG equipment: manufacturing of galvanizing factory equipment from A to Z, including all the necessary equipment and auxiliary equipment.
  • Installation and commissioning: offering installation service and users’ guidance, supply of galvanizing chemicals and adjustment technology.

Treatment effect prediction table:



Pulse bag filter White Fume
Inlet gas concentration 257 mg/m3
Outlet gas concentration 25 mg/m3
Removal rate 95 %
Emission concentration 25 mg/m3
Emission standard 120 mg/m3
Emission rate 2.1 kg/h

Main Equipment

No. HDG Process Equipment Use

Need

Or not

(√)
1 Pickling Enclosed pretreatment workshop Collect acid fume
Acid fume treatment equipment Environment friendly
Pickling electric hoist/crane Transfer
2 Rinsing Wastewater treatment equipment Environment friendly
3 Degreasing Waste heat recycling system Save energy
4 Rinsing Wastewater treatment equipment Environment friendly
5 Fluxing Waste heat recycling system Save energy
Iron removal equipment Recycling
6 Galvanizing Galvanizing furnace body For heating
Zinc kettle Place zinc
White fume fixed hood Collect fume
White fume treatment equipment Environment friendly
Bridge crane/ electric hoist Transfer
7 Cooling Cooling tower Recycling
8 Passivation Chromium-free passivator Good effect
9 Auxiliary Bridge crane/Flat trolley/Material rack/Transfer pit Transfer
Tank’s anti-corrosion protection Safety
Zinc ingot/Chemicals/Alloy Necessity

Service Process

  • Demand communication
  • Custom plant
  • Supply of hot dip galvanizing equipment
  • Assembly and commissioning
  • Supply of galvanizing techniques
  • 24Hr after-sales service

Galvanizing Related Training

  • Theory of hot dip galvanizing
  • The procedure of melting zinc ingots
  • Zinc kettle using guidance
  • Decreasing of fumes
  • Treatment of coating problems
  • Adjustment of chemical additives

Choose Us



Beihai galvanizing- tailor factory for you, the worth of your trust~



Choose us!



For a Win-Win future!
